倍福EL2008 | EtherCAT Terminal, 8-channel digital

點擊圖片查看原圖

店鋪基本資料信息

產品詳細說明

本公司專業銷售德國Beckhoff倍福PLC、PC、模塊IO等產品，價格美麗，庫存充足，歡迎來電咨詢~

Technical data EL2008

Connection technology 1-wire

Number of outputs 8

Nominal voltage 24 V DC (-15 %/+20 %)

Load type ohmic, inductive, lamp load

Distributed clocks –

Max. output current 0.5 A (short-circuit proof) per channel

Short-circuit current typ. < 2 A

Reverse voltage protection yes

Breaking energy < 150 mJ/channel

Switching times typ. TON: 60 µs, typ. TOFF: 300 µs

Current consumption E-bus typ. 110 mA

Electrical isolation 500 V (E-bus/field potential)

Current consumption power contacts typ. 15 mA + load

Bit width in the process image 8 outputs

Configuration no address or configuration setting

Weight approx. 55 g

Operating/storage temperature -25…+60 °C/-40…+85 °C

Relative humidity 95 %, no condensation

Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27

EMC immunity/emission conforms to EN 61000-6-2/EN 61000-6-4

Protect. rating/installation pos. IP20/see documentation

Pluggable wiring for all ESxxxx terminals

Approvals/markings CE, UL, ATEX, IECEx, DNV GL, cFMus

Ex marking ATEX:
II 3 G Ex nA IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
cFMus:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2, AEx ec IIC T4 Gc

Technical data	EL2008
Connection technology	1-wire
Number of outputs	8
Nominal voltage	24 V DC (-15 %/+20 %)
Load type	ohmic, inductive, lamp load
Distributed clocks	–
Max. output current	0.5 A (short-circuit proof) per channel
Short-circuit current	typ. < 2 A
Reverse voltage protection	yes
Breaking energy	< 150 mJ/channel
Switching times	typ. TON: 60 µs, typ. TOFF: 300 µs
Current consumption E-bus	typ. 110 mA
Electrical isolation	500 V (E-bus/field potential)
Current consumption power contacts	typ. 15 mA + load
Bit width in the process image	8 outputs
Configuration	no address or configuration setting
Weight	approx. 55 g
Operating/storage temperature	-25…+60 °C/-40…+85 °C
Relative humidity	95 %, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/see documentation
Pluggable wiring	for all ESxxxx terminals
Approvals/markings	CE, UL, ATEX, IECEx, DNV GL, cFMus
Ex marking	ATEX: II 3 G Ex nA IIC T4 Gc IECEx: Ex ec IIC T4 Gc cFMus: Class I, Division 2, Groups A, B, C, D Class I, Zone 2, AEx ec IIC T4 Gc
