EMERSON/艾默生 ASCO電磁閥 E290系列電磁閥
ANGLE SEATED VALVES
stainless steel body
3/8 - 2 1/2
FEATURES
• High flow due to angled seat design
• Anti-waterhammer design (fluid entry under the disc)
• Vacuum operation up to 10-2 mbar
• Wide range of piston-type operators (32 - 50- 63 - 90 -125 mm dia.) rotatable
through 360°, for maximum performance at different minimum pilot pressures
• High performance, maintenance-free stuffing box
• The valves satisfy Pressure Equipment Directive 97/23/EC, category 1 (DN > 25) or
article 3.3(DN ≤ 25)
